3,500 lb
Rated capacity
Electric
Power
Narrow
Series
The Bobcat BR18SP-7 Plus is a 3,500 lb electric pantograph reach truck built to place pallets deep into double-deep rack. Its extendable reach mast lifts up to 24.1 feet across 7 mast options, well beyond what a standard counterbalance truck can access.
The 36V AC drivetrain runs on a Curtis controller with dual drive motors, and the compact reach chassis keeps the truck inside a narrow aisle while the mast extends forward to place or pull a pallet.
It fits distribution centers and 3PL operations that need to maximize storage density in high-bay racking without widening aisles or expanding the building footprint.
Choose the BR18SP-7 Plus when your heaviest recurring load runs close to a ton and three quarters and your racking runs high-bay double-deep. Tell us your rack height and aisle width, and we will confirm mast and battery configuration.
Companies that run our forklifts*
Specifications
Capacity & load
| Rated load capacity | 3,500 lb |
|---|---|
| Load center | 24 in |
| Configuration | Rider reach truck, pantograph mast |
Electrical & power
| System voltage | 36V |
|---|---|
| Drive system | AC (Curtis controller) |
Dimensions
| Max fork height | 289 in / 24.1 ft (7 mast options) |
|---|---|
| Free lift | up to 77.7 in |
| Overall width | 45.4 in |
| Wheelbase | 58 in |
| Overall length | 72.8 in |
| Outside turning radius | 67.4 in |
| Overhead guard height | 95 in |
Performance & chassis
| Travel speed | 7.5 mph |
|---|---|
| Lift speed (laden / unladen) | 69 / 120 fpm |
| Gradeability (laden) | 10% |
| Service weight | 7,255 lb |
Part of the Narrow Aisle Forklifts range →
Other models in this series
Bobcat BR18SP-7 Plus sales, rentals & service near you
We stock, rent, and service the BR18SP-7 Plus across Southern Indiana, Kentucky, Middle Tennessee, and North & Central Alabama. Find your local team:
BR18SP-7 Plus FAQs
How high can the BR18SP-7 Plus reach?
Up to 24.1 feet (289 in) across 7 mast options, letting it work high-bay double-deep rack that a standard counterbalance truck cannot reach.
How does the BR18SP-7 Plus compare to the BR20SP-7 Plus?
Both are pantograph reach trucks on the same 36V AC platform. The BR18SP-7 Plus carries 3,500 lb to a max 24.1 ft lift height, while the BR20SP-7 Plus steps up to 4,000 lb and reaches 30.5 ft, the tallest mast in the lineup.
